This precision steel mold insert is manufactured using state-of-the-art CNC machining techniques and EDM finishing to ensure exceptional accuracy and surface quality. Designed for demanding injection molding applications, it provides superior wear resistance and dimensional stability. The DIN 1.2344 (H13 Tool Steel) material offers excellent toughness and heat resistance. Ideal for high-volume production environments.
Download our technical datasheet (PDF) for more details.
Material Options
We offer a wide range of material options to meet your specific requirements:
Aluminum (6061, 7075, 5052)
Stainless Steel (304, 316, 420)
Carbon Steel (1018, 1045)
Tool Steel (H13, D2, A2)
Brass, Copper, Bronze
Plastics (ABS, PC, POM, Nylon)
And more – please inquire!
Precision & Tolerance
We are committed to delivering parts with exceptional precision. Our standard tolerance is +/- 0.01mm, but we can achieve tighter tolerances based on your specific needs. We utilize advanced CMM inspection equipment to ensure dimensional accuracy.
Typical Tolerances:
General Linear Tolerance: +/- 0.01mm
Hole Diameter Tolerance: +/- 0.005mm
Surface Finish: Ra 0.2 µm
Machining Processes
We offer a comprehensive range of CNC machining processes:
CNC Milling (3-Axis, 4-Axis, 5-Axis)
CNC Turning
EDM (Wire EDM, Sinker EDM)
Grinding
Drilling
Tapping
Packaging & Shipping
We provide secure and reliable packaging to protect your parts during shipping. Options include:
Individual wrapping with protective film
Custom foam inserts
Wooden crates for larger quantities
Shipping via UPS, FedEx, DHL, or your preferred carrier
Certifications
We are ISO 9001 certified, demonstrating our commitment to quality management.
Equipment Used
We utilize advanced CNC machining equipment from leading manufacturers:
HAAS CNC Milling Machines
DMG MORI CNC Turning Centers
Mitsubishi EDM Machines
Zeiss CMM (Coordinate Measuring Machine)
Mitutoyo Profilometer
Customer Reviews
“Excellent quality and fast turnaround! We highly recommend their services.” – John Doe, Acme Corp.
“The precision of the parts exceeded our expectations. Great communication throughout the process.” – Jane Smith, Beta Industries.
Case Studies
Complex Geometry Machining for Aerospace Application
Successfully manufactured a complex aerospace component with tight tolerances and challenging geometry. Utilized 5-axis milling and wire EDM to achieve the required specifications.
Read More
Related Parts / Services
Custom CNC Machined Parts
Plastic Injection Molding
3D Printing
Rapid Prototyping
“`
